Diode Dynamics Elite Series Yellow Fog Lamps For 2022-2024 Ford Maverick

SKU: DD7769

SELECT FITMENT

See If This Product Fits Your Vehicle

$299.95
$299.95

Free Shipping

Free ground shipping on all orders over $99

While the Ford Maverick doesn’t come with a factory fog light option, there is still a need for light directly in front of the vehicle to increase your visibility in foggy, dusty, snowy, or rainy conditions. Headlights simply weren’t designed to provide this kind of visibility, so that’s where we come in. Introducing our new add-on Elite Series Fog Lamp Kit for the 2022-2024 Ford Maverick! This kit allows you to mount two SAE-compliant fog lamps in the factory bumper, while maintaining an OEM appearance thanks to the custom-designed bezel.

Feature:

  • Adds SAE-compliant fog lights to the 2022+ Ford Maverick
  • OEM appearance with included textured bezel
  • Custom harness allows for factory-like operation
  • Sharp, asymmetric beam pattern achieves 100-degree total spread
  • Distinctive integrated amber backlight
  • Engineered and assembled in USA

Specifications:

  • Measured Lumens: 1900 lm
  • Intensity (cd): 11,000 cd
  • Color Temp (CCT): 3000K
  • Beam Angle: Fog, 80°x6°
  • Power (watts): Main Beam: 21, Backlight: 2.0
  • Operating Voltage: 9-16V
  • Current (amps @ 13.2V): Main Beam: 1.6, Backlight: 0.15
  • Polarity: Polarity Specific Operating Temperature: -40C to 85C (-40F to 185F)
  • LED Emitter: DongFeng DF3E
  • Connector(s): Deutsch DT Input, 9006
  • Driver Features: Internal, Constant Current
  • Materials: Copper PCB, UV Coated Polycarbonate Lens, Powdercoated Aluminum
  • Cooling: Passive, Pin-Fin heatsink
  • Compliance Ratings: SAE J575
  • Durability Test, SAE J578
  • Output Color, SAE J583 Foglamp Beam Pattern
  • Intrusion Ratings: IP69K Waterproof, High Pressure

Fitment:

  • 2022+ Ford Maverick

Product Specs

SKU:
DD7769
Brand:
Diode Dynamics
