Fluidyne Bar Plate Transmission Cooler For 2003-2009 Dodge Ram 2500/3500 Cummins 48RE/68RFE
SKU:
RT-48-0309BP
SELECT FITMENT
See If This Product Fits Your Vehicle
- $599.00
- $599.00
- Unit price
- per
Free Shipping
Free ground shipping on all orders over $99
Keep the 48RE or 68RFE in your 2003-2009 Dodge Ram 2500/3500 5.9L/6.7L Cummins cool under max towing, daily hauling, or serious power with the Fluidyne Extreme Duty Bar Plate Transmission Cooler. It carries 4X the fluid capacity of stock, a bar plate core that out-cools tube-and-fin and stacked plate designs, and a dual-pass flow path that runs transmission fluid through the core twice before it returns to the system.
The exterior is treated with a proprietary heat-wicking powder coating, the core is aerospace-grade aluminum, and the whole unit is TIG welded inside and out for maximum durability and leak resistance. The cooler measures 31.93 in long, 13.43 in tall, and 2.16 in deep with -8AN O-ring inlet and outlet ports. A Fluidyne bar plate line kit is required, sold separately: TLK.68.0709.BP for 68RFE trucks or TLK.48.0307BP for 48RE trucks.
Features:
- 4X the fluid capacity of the stock transmission cooler
- Bar and plate core for superior heat rejection and strength
- Dual-pass flow circulates fluid through the core twice
- Proprietary heat-wicking powder coating pulls heat off the cooler
- Aerospace-grade aluminum construction
- Internally and externally TIG welded for leak resistance
- Handles heavy towing, high torque, and high horsepower use
- Installs with minimal modifications
Specifications:
- Brand: Fluidyne
- Part Number: RT-48-0309BP
- Type: Transmission Cooler
- Core Design: Bar Plate, Dual Pass
- Material: Aerospace-Grade Aluminum
- Length: 31.93 in
- Height: 13.43 in
- Depth: 2.16 in
- Inlet: -8AN O-Ring
- Outlet: -8AN O-Ring
- Transmission: 48RE, 68RFE
Included:
- (1) Fluidyne Extreme Duty Bar Plate Transmission Cooler
Fitment:
- 2003-2009 Dodge Ram 2500 5.9L/6.7L Cummins Diesel (48RE, 68RFE)
- 2003-2009 Dodge Ram 3500 5.9L/6.7L Cummins Diesel (48RE, 68RFE)
Notes:
- Bar plate line kit required, sold separately: TLK.68.0709.BP (68RFE) or TLK.48.0307BP (48RE)
Product Specs
SKU:
RT-48-0309BP
Brand:
Fluidyne
