Holley 12-802-1 110 GPH Blue® Electric Fuel Pump With Regulator - Gasoline Only

The world famous Red®, Blue® and Black® fuel pumps are the most recognized performance pumps of all times. They have been powering racing legends and street enthusiasts alike since the early 70's. Their time proven rotor/vane design is known to get the job done in an affordable package.

Features:

• Tumble polished billet look
• Lower housing casting designed for enhanced fuel flow
• Motor draws only 3 amps current
• Relay kit P/N 12-753 & 7 1/2 amp fuse recommended
• Improved design for street/strip applications
• Not designed for use on aircraft of any type.
• Distinctive “Blue” logo
• Flows 110 GPH (free flow)
• Flows 88 GPH at 9 psi
• maximum pressure is 14 psi
• Includes P/N 12-803 fuel pressure regulator
• Provides constant fuel flow with no pulsation
• Has externally accessible pressure relief valve (max 14 psi)
• Rotor/vane pump design is more tolerant of contaminated fuels
• Weighs only 3 lbs
• Includes mounting bracket
• Repair kits are readily available
• Can be serviced from the pump end
• Not compatible with alcohol or methanol fuels
• Use of safety shut-off switch, P/N 12-810, strongly recommended
• Not designed or recommended for use with fuel injection systems

Specifications:

• Application: Universal
• Bracket Color: Silver
• Brand: Holley
• Emission Code: 5
• Free Flow GPH: 110
• Free Flow LPH: 416
• Fuel System: Carbureted
• Fuel Type: Gasoline
• Inlet Size: 3/8 inch NPT
• Material: Aluminum
• Motor Finish: Silver
• Outlet Size: 3/8 inch NPT
• Product Type: Fuel Pump
• Pump Body Color: Silver
• Warranty: Limited 90 Day
• UPC: 090127484296
• Part Number: 12-802-1

EMISSIONS:

This part is legal for sale or use on Emissions Controlled Vehicles, Uncontrolled (Non-Emissions Controlled) Vehicles, and Racing Use Only Vehicles because it does not affect vehicle emissions and is not covered by emissions regulations.
