Oracle Lighting Skid Plate w/ Integrated LED Emitters Yellow For 2018-2025 Jeep Wrangler JL / 2020-2025 Jeep Gladiator JT
SKU:
5883-006
- $615.99
- $615.99
- Unit price
- per
Free Shipping
Free ground shipping on all orders over $99
Protect the sway bar and steering box of your 2018-2025 Jeep Wrangler JL or 2020-2025 Jeep Gladiator JT and add trail lighting at the same time with the Oracle Lighting Skid Plate with Integrated LED Emitters in yellow. Nine 15W LED modules put out 9,000 lumens from a low mounting position.
Fitment Note:
- Gladiator JT Mojave requires shock reservoir relocation
- Designed for the factory-style bumper; aftermarket bumper or winch fit not guaranteed
9,000 LUMENS OF YELLOW LIGHT
Nine 15W yellow LED modules put out 135W and 9,000 lumens from a low mounting position.
UNDERBODY PROTECTION
The skid plate protects the sway bar and steering box, formed from 3/16 inch steel with a satin black powder coat.
FOCUSED 30 DEGREE BEAM
Precision optics give a focused 30 degree beam, and the IP68 rated modules are DOT, SAE and E9 marked.
REPLACEABLE LED MODULES
Each LED module can be replaced individually.
NO-DRILL INSTALLATION
The no-drill install includes all hardware and a switched relay harness that also connects to the factory AUX switches.
Features:
- Nine 15W yellow LED modules, 135W and 9,000 lumens total
- Underbody protection for the sway bar and steering box
- 3/16 inch steel plate with satin black powder coat
- Precision optics for a focused 30 degree beam
- IP68 rated modules, DOT, SAE and E9 marked
- Each LED module can be replaced individually
- No-drill installation with all hardware included
- Switched relay harness or factory AUX switch connection
Specifications:
- Brand: Oracle Lighting
- Product: Skid Plate with Integrated LED Emitters
- Emitter Color: Yellow
- LED Modules: 9x 15W
- Total Wattage: 135W
- Total Lumens: 9,000
- Power Draw: 6A @ 12V DC
- Beam Width: 30 Degrees
- IP Rating: IP68
- Compliance: DOT, SAE, E9
- Plate: 3/16in Steel
- Finish: Satin Black Powder Coat
- Warranty: 1 Year
Included:
- (1) Skid Plate Lighting System
- (1) Switched Relay Wiring Harness with On/Off Switch
- (1) Set of Mounting Hardware
Fitment:
- 2018-2025 Jeep Wrangler JL
- 2020-2025 Jeep Gladiator JT
Notes:
- 1 Year Warranty
- Gladiator JT Mojave requires shock reservoir relocation
- Warranty does not cover modifications, alterations, or misuse
- Designed for the factory-style bumper; aftermarket bumper or winch fit not guaranteed
