PMF 2.5" Alpha Series Lift Kit
SKU:
PMF-FRD-1412
SELECT FITMENT
See If This Product Fits Your Vehicle
- $3,199.99
- $3,199.99
$0.00- Unit price
- per
Free Shipping
Free ground shipping on all orders over $99
Availability:
Possible lead times of 5-10 business days may occur
The Alpha 2.5 Inch Suspension System is designed for truck owners who want improved ride quality, confident towing manners, and better overall suspension performance without sacrificing factory payload capability. By retaining the factory rear leaf springs and upgrading key suspension components, this system delivers a balanced setup for daily driving, towing, and higher-horsepower applications.
The front suspension utilizes dual-rate coil springs that improve ride comfort while increasing suspension travel by more than 3 inches over stock. In the rear, the factory leaf pack is retained and paired with a traction bar system to improve stability and control under load.
Front Suspension Options
This kit is available with two front link arm configurations, allowing you to tailor the suspension to your driving style and intended use.
Short Arm 4-Link
The Short Arm 4-Link is designed for customers focused on maximum front axle control. It helps reduce wheel hop and keeps the front axle planted during hard launches, sled pulling, and other high-performance situations.
- Excellent axle control under heavy load
- Reduces wheel hop during acceleration
- Ideal for performance-oriented applications
- Suitable for sled pulling and high-horsepower trucks
Ride quality over potholes and sharp road impacts may be slightly firmer than the Adjustable 3-Link option.
Adjustable 3-Link Arms
The Adjustable 3-Link option focuses on ride quality, steering response, and overall drivability while still providing increased strength over factory components.
- Improved steering feel
- Enhanced street manners
- More comfortable ride quality
- Greater suspension articulation
- Improved off-road compliance
Both systems provide caster adjustment for proper alignment and suspension tuning.
Dual-Rate Front Coil Springs
The included dual-rate coil springs are designed to improve both ride quality and suspension performance. Compared to factory springs, they provide increased travel and improved shock absorption while maintaining good road manners.
- More than 3 inches of additional suspension travel
- Smoother ride quality
- Improved off-road performance
- Better suspension control over rough terrain
Adjustable Track Bar
The kit includes a direct replacement adjustable track bar built from heavy-duty materials to help maintain proper axle alignment and steering geometry.
- Direct bolt-in installation
- 1.5 Inch OD x .250 Wall DOM construction
- Oversized 1 Inch QA1 heim joint
- Improved durability and steering stability
- Adjustable for proper axle centering
Rear Suspension System
Rather than using add-a-leafs that can negatively impact ride quality, this system retains the factory rear leaf pack and uses lift blocks to achieve the desired stance.
The included Stage 2 Gusseted Traction Bar Kit helps control axle wrap and wheel hop while maintaining factory payload capacity.
- Retains OEM rear leaf springs
- Maintains factory payload capability
- User-selectable rear block height
- Improves towing stability
- Reduces axle wrap and wheel hop
- Includes Stage 2 Gusseted Traction Bar Kit
The front springs are designed to sit level with a 3.5 Inch rear block.
U-Bolt Options
The system includes 5/8 Inch U-bolts as standard equipment.
- 5/8 Inch U-bolts included standard
- Optional 3/4 Inch U-bolts available for high-horsepower applications
- Available for both SRW and DRW trucks
Leaf Pack Identification
When ordering, determine whether your truck uses a standard leaf pack or a top-mounted overload leaf pack.
- Standard Leaf Pack: Main leaf runs full length from eyelet to eyelet and is typically 2-3 Inches thick.
- Top Mounted Overload: Includes a separate overload leaf positioned above the main leaf pack with a visible spacer between sections.
Shock Options
Multiple shock packages are available depending on your performance goals. All shock options are valved specifically for this suspension system.
Bilstein 5100
- Excellent entry-level upgrade
- Improved ride quality and handling
- Great value for daily-driven trucks
Bilstein 5160
- Remote reservoir design
- Improved heat management
- Enhanced on-road and off-road performance
- Well-suited for harsh environments
PMF Race Series
- Built to order
- Custom tuned to vehicle use and driving style
- Maximum on-road and off-road performance potential
- Ideal for customers seeking the highest level of suspension performance
Product Specs
SKU:
PMF-FRD-1412
Brand:
PMF Suspension
availability remarks:
Possible lead times of 5-10 business days may occur
leveling lift height:
2.5"
part type:
Suspension & Steering
