PPE Raw Cast Aluminum Engine Oil Pan For 2020-2026 Ford Explorer/Lincoln Aviator 3.0L EcoBoost
SKU:
314052400
SELECT FITMENT
See If This Product Fits Your Vehicle
- $233.99
- $233.99
- Unit price
- per
Free Shipping
Free ground shipping on all orders over $99
Upgrade the stock plastic oil pan on your 2020-2026 Ford Explorer or Lincoln Aviator 3.0L EcoBoost to the PPE Heavy-Duty High-Capacity Cast Aluminum Oil Pan for complete oil drainage, improved durability, enhanced cooling, and superior engine protection. The factory plastic pan retains a significant amount of dirty oil sludge at every oil change, contaminating the fresh oil right away; the PPE pan is engineered to drain completely so clean lubrication starts from the first mile.
Cast from high-grade A356.0-T6 aluminum alloy and finished in raw, the pan adds 1.9 quarts of oil capacity for long-lasting heat management. 3/8-inch external cooling fins maximize heat-wicking surface area and stiffen the bottom of the pan, while deep 3/4-inch internal baffles increase fluid contact with the aluminum for better heat transfer and keep the pickup covered by limiting slosh. Fins and baffles together form a cross-bracing structure backed by cast-in gussets, and the included stainless steel drain plug carries a high-temperature neodymium magnet to pull ferrous debris out of the oil.
Features:
- Premium A356.0-T6 heat-treated cast aluminum alloy construction
- Precision cast in permanent steel molds for dimensional accuracy
- Increases oil capacity by 1.9 quarts for higher thermal capacity
- 3/8-inch external fins lower oil temperature and add impact resistance
- Deep 3/4-inch internal baffles improve heat absorption and limit slosh
- Fins and baffles form an ultra-strong cross-bracing structure
- Cast-in gussets support the upper oil pan flange for added rigidity
- Stainless drain plug with neodymium magnet and Viton O-ring included
Specifications:
- Brand: PPE
- Part Type: Engine Oil Pan
- Material: A356.0-T6 Heat-Treated Cast Aluminum Alloy
- Finish: Raw
- Casting Method: Precision Cast, Permanent Steel Mold
- Added Oil Capacity: 1.9 Quarts
- External Fin Height: 3/8 in
- Internal Baffle Depth: 3/4 in
- Drain Plug: Stainless Steel with Neodymium Magnet
- Gasket: Compatible with OEM Gasket
- Engine: 3.0L EcoBoost V6
- OEM Reference: Ford L1MZ-6675-C
- Warranty: Limited Lifetime
Included:
- (1) PPE Cast Aluminum Engine Oil Pan
- (1) Stainless Steel Drain Plug with Neodymium Magnet and Viton O-Ring
Fitment:
- 2020-2026 Ford Explorer ST 3.0L EcoBoost
- 2020-2026 Ford Explorer Platinum 3.0L EcoBoost
- 2020-2026 Ford Police Interceptor Utility 3.0L EcoBoost
- 2020-2026 Lincoln Aviator 3.0L EcoBoost
Notes:
- Limited Lifetime Warranty
- Warranty does not cover modifications, alterations, or misuse
- Compatible with the OEM oil pan gasket
- Direct replacement for the factory plastic oil pan
