ReadyLIFT SST 3" Lift Kit w/ Control Arms/CV Axles For 22-24 Toyota Tundra 4WD

Upgrade your 2022–2024 Toyota Tundra with the ReadyLIFT SST 3" Front / 1.25" Rear Lift Kit, a premium suspension system designed to enhance off-road capability, increase ground clearance, and deliver a bold, leveled stance. This bolt-on kit includes robust tubular upper control arms with corrected ball joint angles, fabricated steel front strut spacers, and precision-machined billet aluminum rear coil spring spacers. It’s engineered to maintain factory ride quality while giving you the clearance to run up to 35x12.50" tires on 18"x9" wheels with +12mm offset—perfect for drivers looking to add aggressive tires without sacrificing comfort.

Now featuring ReadyLIFT’s exclusive CV Axle Kit upgrade, this kit is trail-ready and built to handle extreme 4WD conditions. The high-angle CV axles offer improved articulation, reduced driveline vibration, and enhanced durability—making it ideal for overland adventures and rugged terrain. Rear shock extensions allow you to retain the use of factory rear shocks, ensuring a smooth ride across any surface. With no cutting or welding required, this lift kit is the ultimate bolt-on solution to transform your Tundra’s appearance and capability.

Features:

• 3” front and 1.25” rear lift for a leveled aggressive stance
• High-angle CV axles reduce vibration and boost durability
• Strong tubular steel UCAs with HD ball joints included
• CNC-machined billet aluminum rear coil spring spacers
• Fabricated steel front strut spacers for added strength
• Rear shock extensions retain factory ride comfort
• Fits up to 35x12.50 tires with 18x9 +12mm wheels
• No cutting, welding, or major mods required to install
• Maintains factory ride quality and suspension geometry

Specifications:

• Control Arm Material: Tubular steel
• Strut Spacer Material: Fabricated steel
• Rear Spacer Material: 6061-T6 billet aluminum
• CV Axles: High-angle design for lifted 4WD use
• Shock Extensions: Included for factory shock compatibility
• Finish: Black powder coat on control arms
• Front Lift Height: 3.0 inches
• Rear Lift Height: 1.25 inches
• Tire Fitment: Up to 35x12.50 on 18"x9" wheels (+12mm offset)

Included:

• (2) Tubular Upper Control Arms with heavy-duty ball joints
• (2) Fabricated Steel Front Strut Spacers
• (2) CNC-Machined Billet Aluminum Rear Coil Spring Spacers
• (2) Rear Air Spring Spacers (for air suspension models)
• (2) Rear Shock Extension Brackets
• (2) High-Angle CV Axles (CV Upgrade Kit – 67-52420CV)
• Grade 8 Hardware Kit – nuts, bolts, washers

Fitment:

• 2022-2024 Tundra 2WD/4WD

Notes:

• 3 Year Warranty
• The factory TRD Skid plate will not bolt back up once the kit is installed
• Kit does not fit Tundra TRD PRO, trucks equipped with Load-Leveling Rear Height Control Air Suspension
