SPE Motorsport Billet Oil Filter Housing For 2011-2023 Ford F650 F750 6.7L
SKU:
SPE-S100214
SELECT FITMENT
See If This Product Fits Your Vehicle
- $349.00
- $349.00
- Unit price
- per
Free Shipping
Free ground shipping on all orders over $99
The SPE Motorsport Billet Oil Filter Housing is a CNC-machined upgrade for 2011-2023 Ford F650 and F750 medium-duty trucks running the 6.7L Powerstroke. Built in-house from a solid block of billet aluminum and black anodized for long-term durability, this housing replaces the restrictive factory unit with a design that flows 30% more oil while accepting commercial-grade CAT filtration.
SPE's testing revealed the factory FL2051S filter wasn't the primary flow restriction — the housing itself was. SPE engineered a billet replacement that integrates all factory sensor locations, retains a factory-style gasket for serviceability, and accepts either the CAT 1R-1807 (long, max capacity) or 324-2598 (short, low-clearance) filter. Both filters are 100% efficient at 20 micron and 20% efficient at 4 micron — far beyond OEM. Two auxiliary 1/8" and 1/4" NPT ports allow for turbo oil supply or temperature/pressure sensor mounting. Compatible with the SPE Cast Lower Oil Pan with full access to drain-back bungs and oil pan heater clearance.
Features:
- Black anodized CNC machined billet aluminum housing
- 30% overall oil flow increase vs factory housing
- Accepts CAT 1R-1807 (long) or CAT 324-2598 (short) filter
- Both filters 100% efficient at 20 micron, 20% at 4 micron
- Stainless steel hardware throughout
- Factory-style injection molded Buna N gasket included
- Retains all factory sensor locations
- Two auxiliary oil ports: 1/8" NPT and 1/4" NPT (plugs included)
- Compatible with SPE cast lower oil pan and oil pan heater
- Extends service intervals with greater oil capacity
Specifications:
- Brand: Snyder Performance Engineering (SPE Motorsport)
- Application: 2011-2023 Ford F650/F750 6.7L Powerstroke
- Material: Billet aluminum, CNC machined
- Finish: Black anodized
- Hardware: Stainless steel
- Filter Compatibility: CAT 1R-1807 or CAT 324-2598
- Filter Efficiency: 100% at 20 micron, 20% at 4 micron
- Flow Increase: 30% over OEM
- Auxiliary Ports: 1/8" NPT + 1/4" NPT (plugs included)
- Year Options: 2011-2019 or 2020-2023
- Country of Manufacture: United States
- Warranty: 1 Year Limited
- Fitment Type: Direct OEM replacement
Included:
- (1) Billet oil filter housing (black anodized)
- (1) Factory-style SPE green injection molded gasket
- (1) Billet stainless oil adapter bung
- (1) CAT Filter — 1R-1807 (long) or 324-2598 (short) per selection
- (1) 1/4" NPT plug
- (1) 1/8" NPT plug
- Complete installation hardware kit
Fitment:
- 2011-2023 Ford F650 6.7L Powerstroke
- 2011-2023 Ford F750 6.7L Powerstroke
Notes:
- MUST select correct year option at order: 2011-2019 OR 2020-2023
- MUST select filter option at order: 1R-1807 (long) for max capacity OR 324-2598 (short) for low-clearance
- Compatible with SPE Cast Lower Oil Pan and oil pan heater accessory
- Auxiliary ports allow turbo oil supply or sensor mounting
