SuperATV Honda Rubicon 6" Portal Gear Lift
SKU:
PGH6-3-15-301#AB
SELECT FITMENT
See If This Product Fits Your Vehicle
- $3,099.95
- $3,099.95
$3,391.95- Unit price
- per
Free Shipping
Free ground shipping on all orders over $99
Maximize performance with GDP Portals
Take your Honda Rubicon beyond its limits with SuperATV’s 6" Portal Gear Lift. It gives you a lift and gear reduction in one package. Choose a 30% or 45% gear reduction to get the torque you need for mud, rocks, and hills, while also gaining more ground clearance and the ability to run bigger tires.
Unmatched torque and power
A 30% or 45% gear reduction gives your Rubicon serious power. If you want to tackle deep mud, haul heavy loads, or run massive tires, go with the 45% reduction. If you want to maintain your top speed while boosting torque, the 30% reduction is your best bet.
Protect your drivetrain for the long haul
Extra power means extra strain, but these Honda Rubicon GDP Portals protect your drivetrain. The gear reduction is built into the hub, helping protect your axles, differential, and transmission from excess wear. Since these portals maintain your stock suspension, your axles stay cooler and last longer.
Stronger than the competition
Your Honda Rubicon portals need to be tough enough to handle hard riding. The cast and 6061 billet aluminum housings are built for extreme conditions and reinforced with advanced steel backing plates that are stronger than chromoly.
- Housings are reinforced for gear retention and optimized for oil flow
- Advanced steel alloy backing plates are stronger than chromoly
- Enhance with Portal Blood gear oil formulated for GDP Portals
- No vents for a simpler design that avoids vent-related issues
Advanced gaskets, seals, and bearings
- Advanced gaskets and O-rings with excellent oil resistance and low deterioration rates
- Sealed input gear and double-lipped output seal
- 100% sealing coverage throughout to help prevent oil leaks
- Double-angular contact output bearings to help prevent premature wear
- Roller idler and drive bearings to maintain perfect gear meshing
Features
- Available with billet or cast aluminum housing
- Cool, quiet, precision-ground gears made from 9310 alloy billet steel
- 1.5 in. diameter 4340 hardened steel drive shaft
- Housings use gaskets or O-rings that don’t let anything through
- Universal hub fits all major bolt patterns
- Gear reduction reduces stress on your drivetrain
- Lighter than the competition
6" Portal Gear Lift includes:
- (4) Assembled portal hub boxes complete with 9310 gears, seals, output shaft, gaskets, and thrust bearings
- (4) Universal hubs and precision-ground stainless steel slotted rotors with lugs
- (4) Specialized steel alloy backing plates
- (2) Steel caliper mounting plates
- (2) Caliper mounting plate shims
- Extended brake lines
- All required hardware, including recessed castle nut socket
Honda Rubicon max tire size recommendations
- 28" tires: Stock suspension
- 30" tires: SuperATV Footwells
If you need help figuring out which gear reduction is right for you, check out our .
Max tire sizes are measured at full compression and full turn. The given tire sizes are the largest we fit without rubbing. With minor trimming or a small amount of rub, larger tire sizes can be used.
Fitment
- Honda Rubicon 500: 2015-2019
- Honda Rubicon 520: 2020+
Note: Only compatible on machines with IRS (Independent Rear Suspension).
Wheel requirements
- 18" or larger wheel required
- 20" and larger wheels cannot exceed 5" backspacing
- Wheels need to have a center hole of at least 3.25" (82.55 mm) or require a 1" wheel spacer
Patent # 11,299,042Patent # 11,318,787
Product Specs
SKU:
PGH6-3-15-301#AB
Brand:
SuperATV
