SuperATV Kawasaki Brute Force 4" Portal Gear Lift

SKU: PGH-4-12-151

SELECT FITMENT

See If This Product Fits Your Vehicle

$2,649.95
$2,649.95
$2,941.95

Free Shipping

Free ground shipping on all orders over $99
Portal Housing Material: Cast
Portal Gear Reduction: 15%
Description

Your Kawasaki Brute Force works hard for you—now it’s time to take it to the next level. SuperATV’s 4" Portal Gear Lift gives you the power, ground clearance, and tire clearance you need to conquer the trails. With your choice of a 15% or 30% gear reduction, GDP Portals give you the power and performance you need.

Want more power? With a choice of 15% or 30% gear reduction, you can get the perfect amount of torque for your style. The 30% gear reduction delivers strong torque for hauling and climbing, while the 15% option keeps your top speed intact with a noticeable torque boost.

Extra weight and torque can wear out your drivetrain, but not with GDP Portals. By putting the gear reduction in the hub, your drivetrain stays protected while you power through tough terrain. You also keep your factory suspension for smooth rides and cool-running axles.

GDP Portals feature cast and 6061 billet aluminum housings reinforced with high-strength steel backing plates. They’re built to handle hard rides and keep you going when others might fail.

  • Housings are reinforced for gear retention and optimized for oil flow
  • Advanced steel alloy backing plates are stronger than chromoly
  • Enhance with Portal Blood gear oil formulated for GDP Portals
  • No vents to reduce potential issues

Advanced gaskets, seals, and bearings help keep everything running smoothly:

  • Advanced gaskets and O-rings with excellent oil resistance and low deterioration rates
  • A sealed input gear and double-lipped output seal
  • 100% sealing coverage throughout to help prevent oil leaks
  • Double-angular contact output bearings to help prevent premature wear
  • Roller idler and drive bearings to maintain gear meshing
  • Available with billet or cast aluminum housing
  • Cool, quiet, precision-ground gears made from 9310 alloy billet steel
  • 1.5 in. diameter 4340 hardened steel drive shaft
  • Housings use gaskets or O-rings that help keep contaminants out
  • Universal hub fits all major bolt patterns
  • Gear reduction reduces stress on your drivetrain
  • Lighter than the competition

4" Portal Gear Lift includes:

  • (4) Assembled portal hub boxes complete with 9310 gears, seals, output shaft, gaskets, and thrust bearings
  • (4) Universal hubs and precision-ground stainless steel slotted rotors with lugs
  • (4) Specialized steel alloy backing plates
  • (2) Steel caliper mounting plates
  • (6) Caliper mounting plate shims
  • (2) Caliper spacers
  • Extended brake lines
  • All required hardware, including recessed castle nut socket

Fitment:

  • Kawasaki Brute Force 750: 2012+

Wheel requirements:

  • 14" or larger wheel required
  • Cannot exceed 5" backspacing
  • Not compatible with dual beadlock wheels
  • 1" wheel spacers required on stock wheels

Kawasaki Brute Force Max Tire Size Recommendations:

  • 29" tire size: Stock suspension setup with 4" portals

If you need help figuring out which gear reduction is right for you, check out our .

Max tire sizes are measured at full compression and full turn. The given tire sizes are the largest we fit without rubbing. With minor trimming or a small amount of rub, larger tire sizes can be used.

Patent # 11,299,042Patent # 11,318,787
