SuperATV Kawasaki Mule Pro 4" Portal Gear Lift

SKU: PGH-4-50-151

SELECT FITMENT

See If This Product Fits Your Vehicle

$2,649.95
$2,649.95
$2,941.95

Free Shipping

Free ground shipping on all orders over $99
Portal Housing Material: Cast
Portal Gear Reduction: 15%
Description

Gen 3 Portals are geared for all. SuperATV’s GDP 4" Portal Gear Lift for the Kawasaki Mule Pro is available with either a 15% or 30% gear reduction, giving you the torque and speed balance you need for your ride.

Choose 30% gear reduction for mud, rocks, and bigger tires when you want maximum torque and trail capability. Choose 15% gear reduction for farming and trails when you want added clearance and torque while keeping higher speeds for road travel between fields or on the trail.

These portals feature precision-ground 9310 billet steel alloy gears for cool, quiet operation and durability. Strong housing options include cast aluminum or USA-made, CNC-machined 6061 billet aluminum with reinforced design, improved oil flow, and no vents. Advanced gaskets and seals help resist leaks, with a sealed input gear and double-lipped output seal.

The portal gear lift increases width by 4" per side, for 8" total, and includes a 1.5" diameter 4340 hardened steel drive shaft, no-leak bearings and seals, and a universal hub that fits all major bolt patterns. All necessary hardware, backing plates, brake lines, and instructions are included.

  • Available with billet or cast aluminum housing
  • Cool, quiet, precision ground gears made from 9310 alloy billet steel
  • Increases width by 4 in. per side (8 in. total)
  • 1.5 in. diameter 4340 hardened steel drive shaft
  • No leak bearings and seals
  • Universal hub fits all major bolt patterns
  • Comes complete with all hardware, backing plates, brake lines, and instructions

Portal gear reduction recommendations:

  • Up to 27" tires: stock suspension, 15% reduction
  • 28" tires: 2" lift kit, 15% reduction
  • Up to 27" tires: 1.5" forward front A-arms, 15% reduction
  • 28" to 30" tires: 1.5" forward front A-arms and 1.5" offset rear A-arms, 30% reduction
  • 28" to 30" tires: 1.5" forward front A-arms and 1.5" offset rear A-arms with 2" lift kit, 30% reduction

Gear reductions listed are general guidelines to maintain factory top speed. Installing a larger than recommended gear reduction will result in extra torque and lower top speed. Give us a call for more information.

Fitment:

  • Kawasaki Mule Pro DX : 2016+
  • Kawasaki Mule Pro DXT : 2016+
  • Kawasaki Mule Pro FX : 2016-2023
  • Kawasaki Mule Pro FXR : 2018-2023
  • Kawasaki Mule Pro FXT : 2015-2023
  • Kawasaki Mule Pro FXT Ranch Edition : 2016-2023

Wheel requirements:

  • 14" or larger wheel required
  • Cannot exceed 5" backspacing
  • Not compatible with dual beadlock wheels
  • Wheels need to have a center hole of at least 3.25" (82.55mm) or require a 1" wheel spacer

Patent # 11,299,042
