Baja Designs Squadron 2.0 Pro LED Wide Cornering Clear White Housing Light Pod

SKU: 490005WT-2
$259.95
$259.95

Free Shipping

Free ground shipping on all orders over $99
Description

Not seeing the exact setup you want?

Build a custom Squadron 2.0 kit: choose Sport or Pro, mix beam patterns and lens colors, add rock guards and wiring, and see live pricing. Everything goes to your cart in one click.

Build Your Squadron 2.0 Kit →

Baja Designs announces the next generation of their trusted compact LED light - the Squadron 2.0 Pro. This ALL-NEW design delivers a 41% performance increase over the previous generation with an impressive 5,921 lumens of output at 65 watts in a compact package.

The Squadron 2.0 Pro features next-generation optics designed to provide greater distance, wider coverage, and reduced light spill for improved usable illumination. Enhanced uService® components include secure clip-in reflectors and a redesigned gasket for easier lens changes and improved protection against the elements. A redesigned mounting bracket provides greater vertical adjustability, while the 4-pin Deutsch connector improves wiring harness durability.

Features:

  • Squadron 2.0 Pro - 41% performance increase over previous generation
  • Powerful 5,921-lumen output from a compact LED light
  • Wide Cornering beam provides broad usable illumination
  • Refined optics provide greater coverage with reduced light spill
  • RGBW backlight with 9 selectable colors to match your vehicle
  • Clip-in reflectors stay secure during lens changes
  • Redesigned gasket improves sealing against the elements
  • Redesigned bracket allows greater vertical aiming adjustment
  • 4-pin Deutsch connector improves wiring harness durability
  • Durable gloss white aluminum housing

Specifications:

  • Brand: Baja Designs
  • Series: Squadron 2.0 Pro
  • Type: LED Light
  • Part Number: 490005WT-2
  • Lumens: 5,921
  • Power: 65W / 4.7A @ 13.8V
  • Operating Voltage: 12-32V
  • Lens Pattern: Wide Cornering
  • Lens Color: Clear
  • Housing Color: White
  • Backlight: RGBW - 9 Selectable Colors
  • Connector: 4-Pin Deutsch
  • IP Rating: IP69K
  • ELS Score: 132° / 7.6 / 159 / 4946
  • Number of Lights: 1
  • Sold As: Single Light
  • Performance Increase: 41% Over Previous Generation
  • Warranty: Limited Lifetime

Included:

  • (1) Squadron 2.0 Pro LED Wide Cornering Light (White Housing)
  • (1) Mounting Hardware Set

Fitment:

  • Universal

Notes:

  • Limited Lifetime Warranty
  • Buyer acknowledges that some products may only be used when off-roading, and Buyer will comply with all vehicle and road safety guidelines.

Squadron 2.0 Buying Guide

This listing: Squadron 2.0 Pro · Clear Wide Cornering · Single light, white housing

Squadron 2.0 Sport vs. Pro

Both use the same compact 3.3-inch housing, so the choice comes down to how much light you need and how much power you want to draw.

Squadron 2.0 Sport

3,200 lumens per light

30W / 2.2A @ 13.8V

Best for: Fog lights, ditch lights, work lights, everyday use

Squadron 2.0 ProThis light

5,921 lumens per light

65W / 5.2A @ 13.8V

Best for: Maximum distance and brightness for serious off-road use

Upgrading from original Squadrons? The 2.0 Pro draws more power than the original Pro, so make sure your existing harness and switch are rated for it.

Choosing a Beam Pattern

  • Spot: A tight, long-reaching beam for seeing far down the trail. Popular for ditch lights and A-pillar mounts.

  • Driving/Combo: A balance of distance and spread. The most versatile all-around pattern.

  • Wide Cornering (this light): Wide, short-range light that fills in your peripheral vision. A favorite for fog lights.

  • Work/Scene: Even, wide flood lighting for working around the truck, campsite, or job site.

Baja Amber cuts glare in dust, fog, rain, and snow, while clear delivers the most raw output. Because Squadron 2.0 lenses swap easily, you can change the pattern or color later with a lens kit.

Make It Yours

  • Rock guards: Squadron 2.0 rock guards in black or Baja Amber protect the lens from rock chips and trail debris. Sold individually, so order 2 for a pair.

  • Lens kits: change the beam pattern or color without replacing the light. Squadron 2.0 lens kits fit both Sport and Pro, include a replacement gasket to keep the IP69K seal, and are sold one per light.

  • Wiring: every Squadron 2.0 harness, splitter and extension uses 4-pin Deutsch connectors, so everything plugs together.

Learn more: Squadron 2.0: What's New & Which One to Choose · Build Your Own Squadron 2.0 Setup
